Full Music PX25/n
specifications
PX25/n
Premium mesh plate
Nominal operating conditions and parameters
Filament voltage
4.0 V or 5.0 V*
Nominal filament current
2 A or 1.6 A
Plate voltage
400 V
Grid voltage
-30 V**
Plate current
62.5 mA
Amplification factor
9.5
Mutual Conductance
7.5 mA/V
Grid current
0.05 µA
Plate resistance
1265 ohms
*Alternating-current filament supply or Direct-current filament supply.
**Alternating-current filament supply is used.
