Full
Music 45/n
specifications
|
|
| 45/n
Premium mesh plate |
|
| |
|
| Nominal
operating conditions and parameters
|
|
| |
|
| Filament
voltage |
2,5
V* |
| Nominal
filament current |
1.5
A |
| Plate
voltage |
250
V |
| Grid
voltage |
-50
V** |
| Plate
current |
36
mA |
| Amplification
factor |
3.5 |
| Mutual
Conductance |
|
| Grid
current |
0.05
µA |
| Plate
resistance |
1610
ohms |
| |
|
*Alternating-current
filament supply or Direct-current filament
supply.
**Alternating-current filament supply is
used.
|
|
|
|
|
|
